CHM-6-65-70-27-XH20-F3-3

Obsolete

Luminus Devices Inc.

LED COB CHM6 GEN2 WHT SQU 6500K

Search across all available documentation for this part.

Obsolete

Luminus Devices Inc.

LED COB CHM6 GEN2 WHT SQU 6500K

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	CHM-6-65-70-27-XH20-F3-3	CHM-6-65 Series

CCT (K)	6500 K	6500 K
Color	Cool, White	Cool, White
Configuration	Square	Rectangle, Square
CRI (Color Rendering Index)	70	70 - 80
Current - Max [Max]	720 mA	1.28 - 720 A
Current - Test	480 mA	320 - 640 mA
Height [z]	1.37 mm	1.37 mm
Lens Type	Flat	Flat
Light Emitting Surface (LES) [diameter]	6.3 mm	6.3 mm
Lumens/Watt @ Current - Test	142 lm/W	102 - 142 lm/W
Luminous Flux @ Current/Temperature	1880 lm	670 - 1880 lm
Size / Dimension	-	12 mm
Size / Dimension	-	13 mm
Temperature - Test	85 °C	85 °C
Type	Chip On Board (COB)	Chip On Board (COB)
Viewing Angle	120 °	120 °
Voltage - Forward (Vf) (Typ)	27.4 V	9 - 27.4 V

LED COB CHM6 COOL WHT RECT 6500K

Part	Height [z]	CCT (K)	Viewing Angle	Type	CRI (Color Rendering Index)	Current - Test	Voltage - Forward (Vf) (Typ)	Luminous Flux @ Current/Temperature	Size / Dimension [x]	Size / Dimension [y]	Temperature - Test	Light Emitting Surface (LES) [diameter]	Configuration	Current - Max [Max]	Lumens/Watt @ Current - Test	Color	Lens Type
Luminus Devices Inc. CHM-6-65-80-9-AA00-F2-3	1.37 mm	6500 K	120 °	Chip On Board (COB)	80	640 mA	9 V	670 lm	12 mm	13 mm	85 °C	6.3 mm	Rectangle	1.28 A	116 lm/W	Cool, White	Flat
Luminus Devices Inc. CHM-6-65-80-18-AA00-F2-3	1.37 mm	6500 K	120 °	Chip On Board (COB)	80	320 mA	17.5 V	700 lm	12 mm	13 mm	85 °C	6.3 mm	Rectangle	320 mA	125 lm/W	Cool, White	Flat
Luminus Devices Inc. CHM-6-65-80-9-AA00-F2-5	1.37 mm	6500 K	120 °	Chip On Board (COB)	80	640 mA	9 V	670 lm	12 mm	13 mm	85 °C	6.3 mm	Rectangle	1.28 A	116 lm/W	Cool, White	Flat
Luminus Devices Inc. CHM-6-65-80-18-AA10-F3-5	1.37 mm	6500 K	120 °	Chip On Board (COB)	80	320 mA	17.5 V	700 lm	12 mm	13 mm	85 °C	6.3 mm	Rectangle	640 mA	125 lm/W	Cool, White	Flat
Luminus Devices Inc. CHM-6-65-70-27-XH20-F3-3	1.37 mm	6500 K	120 °	Chip On Board (COB)	70	480 mA	27.4 V	1880 lm			85 °C	6.3 mm	Square	720 mA	142 lm/W	Cool, White	Flat
Luminus Devices Inc. CHM-6-65-70-27-XH20-F3-5	1.37 mm	6500 K	120 °	Chip On Board (COB)	70	480 mA	27.4 V	1880 lm			85 °C	6.3 mm	Square	720 mA	142 lm/W	Cool, White	Flat
Luminus Devices Inc. CHM-6-65-80-27-XH00-F2-5	1.37 mm	6500 K	120 °	Chip On Board (COB)	80	480 mA	27 V	1320 lm			85 °C	6.3 mm	Square	720 mA	102 lm/W	Cool, White	Flat

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

LED Lighting COBs Engines Modules Chip On Board (COB) CHM-6 Gen2 White, Cool Square
