MS3476W24-19SX

Active

Conesys

CONN PLUG FMALE 19POS CRIMP

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

MS3476W24-19SX

Active

Conesys

CONN PLUG FMALE 19POS CRIMP

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 95.85
		10	$ 83.07
		25	$ 73.29
		50	$ 65.58
		100	$ 57.51

Description

General part information

MS3476W24 Series

19 (Power) Position Circular Connector Plug, Female Sockets Crimp

Documents

Technical documentation and resources

Datasheet

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	MS3476W24-19SX	MS3476W24 Series

Applications	Aviation, Military, Industrial	Aviation, Military, Industrial, Automotive
Color	Olive Drab	Olive Drab
Connector Type	Female Sockets, Plug	Female Sockets, Plug, Plug Housing, Male Pins
Contact Finish - Mating	Gold	Gold
Contact Finish Thickness - Mating	1.27 µm	1.27 µm
Contact Finish Thickness - Mating	50 µin	50 µin
Contact Material	Copper Alloy	Copper Alloy
Contact Shape	-	Circular
Contact Size	-	12 - 20
Contact Type	-	Crimp
Current Rating (Amps)	-	23 A
Fastening Type	Bayonet Lock	Bayonet Lock
Features	Coupling Nut	Coupling Nut
Housing Color	-	Olive Drab
Ingress Protection	Environment Resistant	Environment Resistant
Insert Material	-	Plastic
Mounting Type	Free Hanging (In-Line)	Free Hanging (In-Line)
Note	-	Contacts Not Included
Number of Positions	19	19 - 61
Operating Temperature [Max]	200 °C	200 - 347 °C
Operating Temperature [Min]	-65 ░C	-65 - -55 ░C
Orientation	X	N, X, W, Z, Y
Primary Material	Metal	Metal
Qualification	-	MIL-DTL-26482 G Series II
Shell Finish	Olive Drab Cadmium	Olive Drab Cadmium, Chromate over Cadmium
Shell Material	Aluminum	Aluminum, Aluminum Alloy
Shell Size - Insert	24-19	24-19
Shell Size - Insert	-	31 - 61
Shell Size - Insert	-	24
Shielding	Unshielded	Unshielded
Termination	Crimp	Crimp
Type	-	For Female Sockets, For Male Pins

MS3476W24 Series

CONN PLUG FMALE 31POS CRIMP

Part	Contact Finish - Mating	Orientation	Connector Type	Fastening Type	Shell Material	Features	Number of Positions	Primary Material	Termination	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Shell Size - Insert [Max]	Shell Size - Insert [Min]	Applications	Shielding	Color	Shell Finish	Contact Material	Ingress Protection	Contact Shape	Insert Material	Housing Color	Contact Size	Type	Contact Type	Note	Qualification	Shell Size - Insert
Conesys MS3476W24-31S	Gold	N	Female Sockets, Plug	Bayonet Lock	Aluminum	Coupling Nut	31	Metal	Crimp	Free Hanging (In-Line)	-65 ░C	200 °C	1.27 µm	50 µin	31	24	Aviation, Industrial, Military	Unshielded	Olive Drab	Olive Drab Cadmium	Copper Alloy	Environment Resistant
Conesys MS3476W24-19S-LC		N	Plug Housing	Bayonet Lock	Aluminum Alloy	Coupling Nut	19			Free Hanging (In-Line)	-55 °C	347 °F						Unshielded		Chromate over Cadmium		Environment Resistant	Circular	Plastic	Olive Drab	12	For Female Sockets	Crimp	Contacts Not Included	MIL-DTL-26482 G Series II	24-19
Conesys MS3476W24-19PX-LC		X	Plug Housing	Bayonet Lock	Aluminum Alloy	Coupling Nut	19			Free Hanging (In-Line)	-55 °C	347 °F						Unshielded		Chromate over Cadmium		Environment Resistant	Circular	Plastic	Olive Drab	12	For Male Pins	Crimp	Contacts Not Included	MIL-DTL-26482 G Series II	24-19
Conesys MS3476W24-19S	Gold	N	Female Sockets, Plug	Bayonet Lock	Aluminum Alloy		19	Metal	Crimp	Free Hanging (In-Line)	-55 °C	200 °C	1.27 µm	50 µin					Olive Drab	Olive Drab Cadmium											24-19
Conesys MS3476W24-61PW-LC		W	Plug Housing	Bayonet Lock	Aluminum Alloy	Coupling Nut	61			Free Hanging (In-Line)	-55 °C	347 °F			61	24		Unshielded		Chromate over Cadmium		Environment Resistant	Circular	Plastic	Olive Drab	20	For Male Pins	Crimp	Contacts Not Included	MIL-DTL-26482 G Series II
Conesys MS3476W24-19P	Gold	N	Male Pins, Plug	Bayonet Lock	Aluminum Alloy		19	Metal	Crimp	Free Hanging (In-Line)	-55 °C	200 °C	1.27 µm	50 µin					Olive Drab	Olive Drab Cadmium											24-19
Conesys MS3476W24-61PX-LC		X	Plug Housing	Bayonet Lock	Aluminum Alloy	Coupling Nut	61			Free Hanging (In-Line)	-55 °C	347 °F			61	24		Unshielded		Chromate over Cadmium		Environment Resistant	Circular	Plastic	Olive Drab	20	For Male Pins	Crimp	Contacts Not Included	MIL-DTL-26482 G Series II
Conesys MS3476W24-61S	Gold	N	Female Sockets, Plug	Bayonet Lock	Aluminum Alloy		61	Metal	Crimp	Free Hanging (In-Line)	-55 °C	200 °C	1.27 µm	50 µin	61	24			Olive Drab	Olive Drab Cadmium
Conesys MS3476W24-19P-LC		N	Plug Housing	Bayonet Lock	Aluminum Alloy	Coupling Nut	19			Free Hanging (In-Line)	-55 °C	347 °F						Unshielded		Chromate over Cadmium		Environment Resistant	Circular	Plastic	Olive Drab	12	For Male Pins	Crimp	Contacts Not Included	MIL-DTL-26482 G Series II	24-19
