MAX98358EVSYS#TQFN
ActiveAnalog Devices Inc./Maxim Integrated
EVAL SYST AUDIO AMP CLASS D
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAX98358EVSYS#TQFN
ActiveAnalog Devices Inc./Maxim Integrated
EVAL SYST AUDIO AMP CLASS D
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAX98358EVSYS#TQFN | MAX98358 Series |
|---|---|---|
| Board Type | Fully Populated | Fully Populated |
| Features | - | Short-Circuit, Thermal Protection, Depop |
| Max Output Power x Channels @ Load | 2 channels, 3.2 W | 1 - 4 channels |
| Mounting Type | - | Surface Mount |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Output Type | 2-Channel (Stereo) | 2-Channel (Stereo), 1-Channel (Mono) |
| Package / Case | - | WLBGA, 9-WFBGA, 16-WFQFN Exposed Pad |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 9-WLP (1.26x1.26), 16-TQFN (3x3) |
| Type | - | Class D |
| Utilized IC / Part | MAX98358 | MAX98358 |
| Voltage - Supply [Max] | 5.5 V | 5.5 V |
| Voltage - Supply [Min] | 2.5 V | 2.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 74.44 | |
MAX98358 Series
IC AMP CLASS D STEREO 3.2W 9WLP
| Part | Mounting Type | Voltage - Supply [Min] | Voltage - Supply [Max] | Output Type | Package / Case | Type | Supplier Device Package | Max Output Power x Channels @ Load | Operating Temperature [Max] | Operating Temperature [Min] | Features | Utilized IC / Part | Board Type | Supplied Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAX98358EWL+T | Surface Mount | 2.5 V | 5.5 V | 2-Channel (Stereo) | 9-WFBGA, WLBGA | Class D | 9-WLP (1.26x1.26) | 2 channels, 3.2 W | 85 °C | -40 °C | Depop, Short-Circuit, Thermal Protection | |||
Analog Devices Inc./Maxim Integrated MAX98358ETE+T | Surface Mount | 2.5 V | 5.5 V | 1-Channel (Mono) | 16-WFQFN Exposed Pad | Class D | 16-TQFN (3x3) | 1, 3.2 W, 4 Ohm | 85 °C | -40 °C | Depop, Short-Circuit, Thermal Protection | |||
Analog Devices Inc./Maxim Integrated MAX98358EVSYS#WLP | 2.5 V | 5.5 V | 2-Channel (Stereo) | 2 channels, 3.2 W | MAX98358 | Fully Populated | Board(s) | |||||||
Analog Devices Inc./Maxim Integrated MAX98358EVSYS#TQFN | 2.5 V | 5.5 V | 2-Channel (Stereo) | 2 channels, 3.2 W | MAX98358 | Fully Populated | Board(s) | |||||||
Analog Devices Inc./Maxim Integrated MAX98358ETE+ | Surface Mount | 2.5 V | 5.5 V | 1-Channel (Mono) | 16-WFQFN Exposed Pad | Class D | 16-TQFN (3x3) | 1, 3.2 W, 4 Ohm | 85 °C | -40 °C | Depop, Short-Circuit, Thermal Protection |
