General part information
Electrical Enclosures Aluminum Enclosure with Mounting Flanges Black (2.5 X 2.3 X 1.4 In)
Technical documentation and resources
Parameters and characteristics for this part
| Specification | AN-1319-A |
|---|---|
| Area (L x W) | 9.17 in² |
| Area (L x W) | 59.2 cm² |
| Color | Natural |
| Container Type | Box |
| Design | Cover Included |
| Features | PCB Supports, Watertight |
| Height [z] | 2.05 in |
| Height [z] | 52.07 mm |
| Material | Metal, Aluminum |
| Ratings | NEMA 12, IP68, NEMA 6P, NEMA 6, NEMA 13, NEMA 4X |
| Size / Dimension | 74.42 mm, 79.5 mm |
| Size / Dimension [x] | 3.13 " |
| Size / Dimension [y] | 2.93 in |
| Thickness | 1.8 mm |
| Thickness | 0.071 in |
| Weight | 0.5 lbs |
| Weight | 226.8 g |
Electrical Enclosures Aluminum Enclosure with Mounting Flanges Black (2.5 X 2.3 X 1.4 In)
| Part | Weight | Weight | Ratings | Area (L x W) | Area (L x W) | Material | Height [z] | Height [z] | Thickness | Thickness | Design | Size / Dimension | Size / Dimension [y] | Size / Dimension [x] | Container Type | Features | Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
BUD INDUSTRIES AN-1319-A | 0.5 lbs | 226.8 g | IP68, NEMA 12, NEMA 13, NEMA 4X, NEMA 6, NEMA 6P | 9.17 in² | 59.2 cm² | Aluminum, Metal | 2.05 in | 52.07 mm | 1.8 mm | 0.071 in | Cover Included | 74.42 mm, 79.5 mm | 2.93 in | 3.13 " | Box | PCB Supports, Watertight | Natural |
