VLS252012CX-3R3M
ObsoleteTDK Corporation
FIXED IND 3.3UH 1.53A 137MOHM SM
VLS252012CX-3R3M
ObsoleteTDK Corporation
FIXED IND 3.3UH 1.53A 137MOHM SM
Description
General part information
VLS252012CX-3R3M
3.3 µH Shielded Drum Core, Wirewound Inductor 1.53 A 137mOhm Max 1008 (2520 Metric)
Technical Specifications
Parameters and characteristics for this part
| Specification | VLS252012CX-3R3M |
|---|---|
| Current - Saturation (Isat) | 1.31 A |
| Current Rating | 1.53 A |
| DC Resistance (DCR) (Max) | 137 mOhm |
| Height - Seated (Max) | 0.047 in |
| Inductance | 3.3 µH |
| Inductance Frequency - Test | 1 MHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 1008 (2520 Metric) |
| Package Name | 2520 |
| Shielding | Shielded |
| Size / Dimension Length | 0.098 in |
| Size / Dimension Width | 0.079 in |
| Supplier Device Package | 2520 |
| Tolerance | 20 % |
| Type | Drum Core, Wirewound |
