1700143
ActivePhoenix Contact
TERM BLOCK PLUG 2POS 5MM
1700143
ActivePhoenix Contact
TERM BLOCK PLUG 2POS 5MM
Description
General part information
1700143
2 Position Terminal Block Plug, Female Sockets 0.197" (5.00mm) Free Hanging (In-Line)
Technical Specifications
Parameters and characteristics for this part
| Specification | 1700143 |
|---|---|
| Color | Gray |
| Contact Mating Finish | Tin |
| Current - IEC | 12 A |
| Features | Release Lever |
| Housing Material | Nylon, Polyamide, PA |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Levels | 1 |
| Number of Positions | 2 |
| Pitch | 0.197 in |
| Positions Per Level | 2 |
| Screw Size | M3 |
| Termination Style | Screw - Rising Cage Clamp |
| Torque - Screw (Maximum) | 0.6 Nm |
| Torque - Screw (Minimum) | 0.5 Nm |
| Type | Female Sockets, Plug |
| Voltage - IEC | 250 V |
| Wire Gauge or Range - AWG (Max) | 30 AWG |
| Wire Gauge or Range - AWG (Min) | 12 AWG |
| Wire Gauge or Range - mm² (Maximum) | 2.5 mm² |
| Wire Gauge or Range - mm² (Minimum) | 0.2 mm² |
| Wire Strip Length | 7 mm |
