Y172510K0000V9L
ActiveVPG Foil Resistors
V/N 302073T 10K000 0.005%
Y172510K0000V9L
ActiveVPG Foil Resistors
V/N 302073T 10K000 0.005%
Description
General part information
Y172510K0000V9L
10 kOhms ±0.005% 0.75W, 3/4W Through Hole Resistor Axial - 4 Leads Moisture Resistant, Non-Inductive Metal Foil
Technical Specifications
Parameters and characteristics for this part
| Specification | Y172510K0000V9L |
|---|---|
| Composition | Metal Foil |
| Features | Moisture Resistant, Non-Inductive |
| Number of Terminations | 4 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package Leads | 4 Leads |
| Package Name | Axial, Axial - 4 Leads |
| Power (Watts) | 750 mW |
| Power (Watts) Options | 3/4W |
| Resistance | 10 kOhm |
| Size / Dimension Diameter | 0.5 in |
| Size / Dimension Length | 0.625 in |
| Temperature Coefficient | 2 ppm/°C |
| Tolerance | 0.005 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
