MYC-C7Z010-V2-4E1D-667-C
ActiveMYIR Tech Limited
SYSTEM-ON-MODULE, ZYNQ-7010
MYC-C7Z010-V2-4E1D-667-C
ActiveMYIR Tech Limited
SYSTEM-ON-MODULE, ZYNQ-7010
Description
General part information
MYC-C7Z010-V2-4E1D-667-C
MYC-C7Z010 Embedded Module ARM® Cortex®-A9 Zynq-7000 (Z-7010) 866MHz 1GB 4GB eMMC, 32MB QSPI
Technical Specifications
Parameters and characteristics for this part
| Specification | MYC-C7Z010-V2-4E1D-667-C |
|---|---|
| Co-Processor | Zynq-7000 (Z-7010) |
| Connector Type | Pin(s) |
| Core Processor | ARM® Cortex®-A9 |
| Flash Size (eMMC) | 4 GB |
| Flash Size (QSPI) | 32 MB |
| Flash Type | QSPI, eMMC |
| Module/Board Type | FPGA, MPU |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | 0 °C |
| RAM Size | 1 GB |
| Size / Dimension Length | 2.953 in |
| Size / Dimension Width | 2.165 in |
| Speed | 866 MHz |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
