Description
General part information
R533R4470JAP1M
4.7 µF Film Capacitor 310V 630V Polypropylene (PP), Metallized Radial
Technical Specifications
Parameters and characteristics for this part
| Specification | R533R4470JAP1M |
|---|---|
| Applications | EMI, Automotive, RFI Suppression |
| Capacitance | 4.7 µF |
| Dielectric Material | Metallized, Polypropylene (PP) |
| Height - Seated (Max) | 1.114 in |
| Lead Spacing | 1.083 in |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 110 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Radial |
| Ratings | X2, AEC-Q200 |
| Size / Dimension Length | 1.26 in |
| Size / Dimension Width | 0.551 in |
| Termination | PC Pins |
| Tolerance | 20 % |
| Voltage Rating - AC | 310 V |
| Voltage Rating - DC | 630 V |
