Description
General part information
DPA120200-P1P
12VAC 200mA AC/AC External Wall Mount Adapter Fixed Blade Input
Technical Specifications
Parameters and characteristics for this part
| Specification | DPA120200-P1P |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) | 200 mA |
| Form | Wall Mount |
| Input Connector | NEMA 1-15P |
| Input Type | Fixed Blade |
| Output Connector | Phono Plug |
| Output Connector Length | 14.5 mm |
| Output Connector Outer Diameter | 3.5 mm |
| Power (Watts) | 2 w |
| Region Utilized | North America |
| Voltage - Input | 120 VAC |
| Voltage - Output | 12 V |
