Specification	31330107

Color	Black
Contact Material	Copper Alloy
Contact Mating Finish	Silver
Contact Tail Length	0.136 in
Current - UL	15 A
Header Orientation	Right Angle
Header Orientation Angle	90 °
Housing Material	Nylon 6/6, Polyamide, PA66
Insulation Height	0.331 in
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Levels	1
Number of Positions	7
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-40 °C
Pitch	0.197 in
Positions Per Level	7
Termination Style	Solder
Type	Shrouded (4 Side), Male Pins, Header
Voltage - UL	300 V
