FE3 7/8 BLACK SPL

Active

Sumitomo Electric Interconnect Products, Inc.

HEATSHRINK 7/8" BLACK FOOT

Search across all available documentation for this part.

Active

Sumitomo Electric Interconnect Products, Inc.

HEATSHRINK 7/8" BLACK FOOT

Technical Specifications

Parameters and characteristics for this part

Specification	FE3 7/8 BLACK SPL

Color	Black
Features	Fluid Resistant, Flame Retardant
Inner Diameter - Recovered [diameter]	0.437 "
Inner Diameter - Recovered [diameter]	11.1 mm
Inner Diameter - Supplied [diameter]	22.23 mm
Inner Diameter - Supplied [diameter]	0.875 in
Length	Enter Number of Feet in Order Quantity
Material	Fluoroelastomer (FKM)
Operating Temperature [Max]	200 °C
Operating Temperature [Min]	-40 °C
Recovered Wall Thickness	1.24 mm
Recovered Wall Thickness	0.049 "
Shrink Temperature	120 °C
Shrinkage Ratio	2 to 1
Spool Size	91.4 m
Spool Size	300 ft
Type	Tubing, Flexible

HEATSHRINK 7/8" BLACK FOOT

Part	Spool Size	Spool Size	Material	Length	Inner Diameter - Recovered [diameter]	Inner Diameter - Recovered [diameter]	Type	Inner Diameter - Supplied [diameter]	Inner Diameter - Supplied [diameter]	Operating Temperature [Max]	Operating Temperature [Min]	Shrinkage Ratio	Shrink Temperature	Color	Recovered Wall Thickness	Recovered Wall Thickness	Features
Sumitomo Electric Interconnect Products, Inc. FE3 7/8 BLACK SPL	91.4 m	300 ft	Fluoroelastomer (FKM)	Enter Number of Feet in Order Quantity	0.437 "	11.1 mm	Tubing, Flexible	22.23 mm	0.875 in	200 °C	-40 °C	2 to 1	120 °C	Black	1.24 mm	0.049 "	Flame Retardant, Fluid Resistant

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Heat Shrink Tubing, Flexible 0.875" (22.23mm) 2 to 1 Black Enter Number of Feet in Order Quantity

Technical documentation and resources
