ZSDR-230+

Active

MINI-CIRCUITS

IC RF SWITCH SPDT 3GHZ

Search across all available documentation for this part.

Active

MINI-CIRCUITS

IC RF SWITCH SPDT 3GHZ

Technical Specifications

Parameters and characteristics for this part

IC RF SWITCH SPDT 3GHZ

Part	Package / Case	Insertion Loss	Circuit	Isolation	Frequency Range [Max]	Frequency Range [Min]	Impedance	Topology	RF Type	Operating Temperature [Max]	Operating Temperature [Min]	P1dB [Min]	Test Frequency
MINI-CIRCUITS ZSDR-230+	Module	1.8 dB	SPDT	35 dB	3 GHz	10 MHz	50 Ohms	Reflective	General Purpose	100 °C	-55 °C	19 dBm	3 GHz

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

RF Switch IC General Purpose SPDT 50Ohm
