A8D10RA29CM233

Active

TE Connectivity AMP Connectors

CONN EDGE DUAL FMALE 20POS 0.100

Search across all available documentation for this part.

Active

TE Connectivity AMP Connectors

CONN EDGE DUAL FMALE 20POS 0.100

Technical Specifications

Parameters and characteristics for this part

Specification	A8D10RA29CM233

Card Thickness [Max]	0.071 in
Card Thickness [Max]	1.8 mm
Card Thickness [Min]	0.054 "
Card Thickness [Min]	1.37 mm
Card Type	Non Specified - Dual Edge
Color	Black
Contact Finish	Gold
Contact Finish Thickness	0.76 Ám
Contact Finish Thickness	30 Áin
Contact Material	Copper Alloy
Gender	Female
Material - Insulation	Thermoplastic, Glass Filled
Mounting Type	Through Hole, Right Angle
Number of Positions	20
Number of Positions/Bay/Row [custom]	10
Number of Rows	2
Pitch [x]	2.54 mm
Pitch [x]	0.1 in
Read Out	Dual
Termination	Solder

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

CONN EDGE DUAL FMALE 20POS 0.100

Part	Number of Rows	Card Thickness [Min]	Card Thickness [Min]	Card Thickness [Max]	Card Thickness [Max]	Contact Material	Contact Finish Thickness	Contact Finish Thickness	Read Out	Termination	Color	Material - Insulation	Card Type	Pitch [x]	Pitch [x]	Gender	Mounting Type	Number of Positions	Number of Positions/Bay/Row [custom]	Contact Finish
TE Connectivity AMP Connectors A8D10RA29CM233	2	0.054 "	1.37 mm	0.071 in	1.8 mm	Copper Alloy	0.76 Ám	30 Áin	Dual	Solder	Black	Thermoplastic, Glass Filled	Non Specified - Dual Edge	2.54 mm	0.1 in	Female	Through Hole, Right Angle	20	10	Gold

General part information

20 Position Female Connector Non Specified - Dual Edge Gold 0.100" (2.54mm) Black

Technical documentation and resources

No documents available
