CDB260W-1300-280-R

Active

ERP Power, LLC

LED DRVR CC AC/DC 260W DIM

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

CDB260W-1300-280-R

Active

ERP Power, LLC

LED DRVR CC AC/DC 260W DIM

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	CDB260W-1300-280-R	CDB260W Series

Approval Agency	CE, CB, cULus	CE, CB, cULus
Current - Output (Max)	1.3 A, 930 mA	1.24 - 930 A
Dimming	Bluetooth, Analog	Bluetooth, Analog
Efficiency	93 %	93 %
Features	OTP, SCP, OCP	OTP, SCP, OCP
Mounting Type	Chassis Mount	Chassis Mount
Number of Outputs	1	1
Power (Watts)	260 W	260 W
Ratings	IP66	IP66
Size / Dimension [x]	216.9 mm	216.9 mm
Size / Dimension [x]	8.54 in	8.54 in
Size / Dimension [y]	2 in	2 in
Size / Dimension [y]	50.8 mm	50.8 mm
Size / Dimension [z]	1.52 in	1.52 in
Size / Dimension [z]	38.6 mm	38.6 mm
Termination Style	Wire Leads	Wire Leads
Topology	AC DC Converter	AC DC Converter
Type	Constant Current	Constant Current
Voltage - Input (Max) [Max]	305 VAC	305 VAC
Voltage - Input (Min) [Min]	90 VAC	90 VAC
Voltage - Output [Max]	280 V, 200 V	150 - 400 V
Voltage - Output [Min]	213 V, 152 V	114 - 304 V

CDB260W Series

LED DRVR CC AC/DC 260W DIM

Part	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Efficiency	Dimming	Ratings	Mounting Type	Voltage - Output [Max]	Voltage - Output [Min]	Voltage - Input (Min) [Min]	Features	Termination Style	Topology	Approval Agency	Voltage - Input (Max) [Max]	Number of Outputs	Current - Output (Max)	Power (Watts)	Type
ERP Power, LLC CDB260W-1700-210-W	216.9 mm	8.54 in	1.52 in	2 in	38.6 mm	50.8 mm	93 %	Analog, Bluetooth	IP66	Chassis Mount	150 V, 210 V	114 V, 160 V	90 VAC	OCP, OTP, SCP	Wire Leads	AC DC Converter	CB, CE, cULus	305 VAC	1	1.24 A, 1.7 A	260 W	Constant Current
ERP Power, LLC CDB260W-1700-210-R	216.9 mm	8.54 in	1.52 in	2 in	38.6 mm	50.8 mm	93 %	Analog, Bluetooth	IP66	Chassis Mount	150 V, 210 V	114 V, 160 V	90 VAC	OCP, OTP, SCP	Wire Leads	AC DC Converter	CB, CE, cULus	305 VAC	1	1.24 A, 1.7 A	260 W	Constant Current
ERP Power, LLC CDB260W-1300-280-R	216.9 mm	8.54 in	1.52 in	2 in	38.6 mm	50.8 mm	93 %	Analog, Bluetooth	IP66	Chassis Mount	200 V, 280 V	152 V, 213 V	90 VAC	OCP, OTP, SCP	Wire Leads	AC DC Converter	CB, CE, cULus	305 VAC	1	1.3 A, 930 mA	260 W	Constant Current
ERP Power, LLC CDB260W-1300-280-W	216.9 mm	8.54 in	1.52 in	2 in	38.6 mm	50.8 mm	93 %	Analog, Bluetooth	IP66	Chassis Mount	200 V, 280 V	152 V, 213 V	90 VAC	OCP, OTP, SCP	Wire Leads	AC DC Converter	CB, CE, cULus	305 VAC	1	1.3 A, 930 mA	260 W	Constant Current
ERP Power, LLC CDB260W-0860-400-W	216.9 mm	8.54 in	1.52 in	2 in	38.6 mm	50.8 mm	93 %	Analog, Bluetooth	IP66	Chassis Mount	300 V, 400 V	228 V, 304 V	90 VAC	OCP, OTP, SCP	Wire Leads	AC DC Converter	CB, CE, cULus	305 VAC	1	650 mA, 860 mA	260 W	Constant Current
ERP Power, LLC CDB260W-0860-400-R	216.9 mm	8.54 in	1.52 in	2 in	38.6 mm	50.8 mm	93 %	Analog, Bluetooth	IP66	Chassis Mount	300 V, 400 V	228 V, 304 V	90 VAC	OCP, OTP, SCP	Wire Leads	AC DC Converter	CB, CE, cULus	305 VAC	1	650 mA, 860 mA	260 W	Constant Current

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 108.36
		5	$ 105.07
		10	$ 101.79
		25	$ 98.51

Description

General part information

CDB260W Series

930mA, 1.3A 213 ~ 280V, 152 ~ 200V Constant Current LED Driver AC DC Converter Topology 1 Output
