FBU321611T-330Y-S
ActiveCal-Chip Electronics, Inc.
FB ULTRA 1206 33 OHM 6A .006DC
FBU321611T-330Y-S
ActiveCal-Chip Electronics, Inc.
FB ULTRA 1206 33 OHM 6A .006DC
Description
General part information
FBU321611T-330Y-S
33 Ohms @ 100 MHz 1 Power Line Ferrite Bead 1206 (3216 Metric) 6A 6mOhm
Technical Specifications
Parameters and characteristics for this part
| Specification | FBU321611T-330Y-S |
|---|---|
| Current Rating (Max) | 6 A |
| DC Resistance (DCR) (Max) | 6 mOhm |
| Filter Type | Power Line |
| Height (Max) | 0.051 in |
| Impedance | 33 Ohms |
| Mounting Type | Surface Mount |
| Number of Lines | 1 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 1206 (3216 Metric) |
| Size / Dimension Length | 0.126 in |
| Size / Dimension Width | 0.063 in |
