20UL3173STRVIO250
ActiveRemington Industries
#20 UL3173 600V WIRE VIO 250'
20UL3173STRVIO250
ActiveRemington Industries
#20 UL3173 600V WIRE VIO 250'
Description
General part information
20UL3173STRVIO250
20 AWG Hook-Up Wire 10/30 Violet 600V 250.0' (76.2m)
Technical Specifications
Parameters and characteristics for this part
| Specification | 20UL3173STRVIO250 |
|---|---|
| Cable Type | Hook-Up |
| Conductor Material | Tinned, Copper |
| Conductor Strand Count | 10 |
| Conductor Strand Gauge | 30 |
| Features | Corrosion Resistant, Oil Resistant, Abrasion Resistant, Chemical Resistant, Solvent Resistant |
| Jacket (Insulation) Diameter | 0.103 in |
| Jacket (Insulation) Material | Polyethylene (XLPE) |
| Jacket (Insulation) Thickness | 0.03 in |
| Jacket Color | Violet |
| Length | 250 ft |
| Operating Temperature | 125 °C |
| Ratings | 3173, Style, UL |
| Voltage | 600 V |
| Wire Gauge | 20 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
