General part information
Pushbutton Switches MCS 18 Fp. qd. sw-rt
Technical documentation and resources
Parameters and characteristics for this part
| Specification | 1241.1100.7058 |
|---|---|
| Actuator Marking | No Marking |
| Circuit | SPST-NO |
| Current Rating (Amps) | 125 mA |
| Electrical Life | 1000000 Cycles |
| Features | Tactile Feedback |
| Ingress Protection | IP65 - Dust Tight, Water Resistant |
| Mechanical Life | 1000000 Cycles |
| Mounting Type | Panel Mount, Snap-In |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -25 °C |
| Panel Cutout Dimensions [diameter] | 13 mm |
| Switch Function | Off-Mom |
| Termination Style | Solder Lug |
| Type | Standard |
| Voltage Rating - DC | 48 V |
Pushbutton Switches MCS 18 Fp. qd. sw-rt
| Part | Features | Voltage Rating - DC | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Actuator Marking | Switch Function | Current Rating (Amps) | Circuit | Ingress Protection | Termination Style | Type | Mechanical Life | Electrical Life | Panel Cutout Dimensions [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SCHURTER Inc. 1241.1100.7058 | Tactile Feedback | 48 V | -25 °C | 60 °C | Panel Mount, Snap-In | No Marking | Off-Mom | 125 mA | SPST-NO | IP65 - Dust Tight, Water Resistant | Solder Lug | Standard | 1000000 Cycles | 1000000 Cycles | 13 mm |
