DX30 Series

Part	Color	Hardware	Shielding	Cable Type	Material	Primary Material	Cable Exit Angle	Features	Accessory Type	Number of Positions	Tool Type	For Use With/Related Products	Mounting Type	Contact Finish Thickness	Contact Finish	Flange Feature	Connector Type	Number of Rows	Connector Style	Type	Termination
Hirose Electric Co Ltd DX30M-20-CV	Beige	Strain Relief	Shielded	Round	Metal Shell Plastic Cover Stainless Steel	Metal	180 °	Latch Lock	Two Piece Backshell and Cover	20
Hirose Electric Co Ltd DX30M-20-CV(13)
Hirose Electric Co Ltd DX30AM-HPT1-100											Insertion Tool	D-Sub Connectors
Hirose Electric Co Ltd DX30A-36S(50)										36			Free Hanging (In-Line)	7.87 µin	Gold	Latchblocks Mating Side (M2.6)	Receptacle	2	Outer Shroud Contacts	Miniature High Density (HD)	IDC
Hirose Electric Co Ltd DX30A-50S-LNA(55)										50			Free Hanging (In-Line)	7.87 µin	Gold	Female Screwlock (M2.6) Latchblocks Mating Side	Receptacle	2	Outer Shroud Contacts	Miniature High Density (HD)	IDC
Hirose Electric Co Ltd DX30AM-CAT1									Cable Distribution
Hirose Electric Co Ltd DX30AM-14P										14			Free Hanging (In-Line)		Gold		Plug	2	Center Strip Contacts	Miniature High Density (HD)	IDC
Hirose Electric Co Ltd DX30AM-GPT1									Guide Plate Locator
Hirose Electric Co Ltd DX30A-20P(57)										20			Free Hanging (In-Line)	30 µin	Gold	Latchblocks Mating Side (M2.6)	Plug	2	Center Strip Contacts	Miniature High Density (HD)	IDC
Hirose Electric Co Ltd DX30A-36P(50)										36			Free Hanging (In-Line)	7.87 µin	Gold	Latchblocks Mating Side (M2.6)	Plug	2	Center Strip Contacts	Miniature High Density (HD)	IDC
