Description
General part information
PYBE30-Q24-D15H
Isolated Module DC DC Converter 2 Output 15V -15V 1A, 1A 9V - 36V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | PYBE30-Q24-D15H |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | cURus |
| Current - Output (Max) | 1 A |
| Efficiency | 89 % |
| Features | Adjustable Output, Remote On/Off, Heat Sink |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Operating Temperature (Max) | 80 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 6-DIP Module |
| Power (Watts) | 30 W |
| Size / Dimension Height | 0.65 in |
| Size / Dimension Length | 2.02 in |
| Size / Dimension Width | 1.03 in |
| Standard Number | 62368-1, 60950-1 |
| Type | Isolated Module |
| Voltage - Input (Max) | 36 V |
| Voltage - Input (Min) | 9 V |
| Voltage - Isolation | 1500 Vrns |
| Voltage - Output 1 | 15 V |
| Voltage - Output 2 | -15 V |
