Description
General part information
PEH226HG4220ME4
2.2 mF 25 V Aluminum Electrolytic Capacitors Radial, Can - Solder Lug 51mOhm @ 100Hz 1500 Hrs @ 150°C
Technical Specifications
Parameters and characteristics for this part
| Specification | PEH226HG4220ME4 |
|---|---|
| Applications | Automotive |
| Capacitance | 2.2 mF |
| ESR (Equivalent Series Resistance) | 51 mOhm |
| Height - Seated (Max) | 1.445 in |
| Lead Spacing | 0.6 in |
| Lifetime | 1500 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Radial, Can - Solder Lug |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Ripple Current | 7.2 A, 2.52 A |
| Size / Dimension Diameter | 0.638 in |
| Tolerance | 20 % |
| Voltage - Rated | 25 VAC |
