GG-17CS
ActiveCentury Spring Corp
COMP O= .188,L= 1.28,W= .020
GG-17CS
ActiveCentury Spring Corp
COMP O= .188,L= 1.28,W= .020
Description
General part information
GG-17CS
COMP O= .188,L= 1.28,W= .020
Technical Specifications
Parameters and characteristics for this part
| Specification | GG-17CS |
|---|---|
| Diameter - Inside | 0.148 in |
| Diameter - Outside | 0.188 in |
| End Style | Ground, Closed |
| Finish | None |
| Free Length | 1.28 in |
| Material | Stainless Steel |
| Rate (lbs/in) | 2.5 lbs/in |
| Type | Compression |
| Wire Diameter | 0.02 in |
