AM6GH-2412SNZ

Obsolete

DComponents

DC DC CONVERTER 12V 6W

Search across all available documentation for this part.

Obsolete

DComponents

DC DC CONVERTER 12V 6W

Technical Specifications

Parameters and characteristics for this part

DC DC CONVERTER 12V 6W

Part	Applications	Voltage - Input (Max) [Max]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Supplier Device Package	Current - Output (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Type	Mounting Type	Number of Outputs	Efficiency	Power (Watts)	Voltage - Input (Min) [Min]	Package / Case	Voltage - Output 1	Features	Voltage - Isolation
DComponents AM6GH-2412SNZ	ITE (Commercial)	36 V	0.47 "	22 mm	0.37 "	0.87 in	9.5 mm	12 mm	8-SIP	500 mA	-40 °C	105 ░C	Isolated Module	Through Hole	1	86 %	6 W	9 V	8-SIP Module	12 V	Remote On/Off	1.6 kV

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Isolated Module DC DC Converter 1 Output 12V 500mA 9V - 36V Input
