FAD1-12038EBMW12
ActiveQualtek
FAN AXIAL 120X38.5MM 48VDC WIRE
Deep-Dive with AI
Search across all available documentation for this part.
FAD1-12038EBMW12
ActiveQualtek
FAN AXIAL 120X38.5MM 48VDC WIRE
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | FAD1-12038EBMW12 |
|---|---|
| Air Flow | 96.3 CFM |
| Air Flow | 2.7 m³/min |
| Approval Agency | cURus, CE, TUV |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Noise | 45 dB(A) |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -10 °C |
| Operating Temperature [Min] | -10 °C |
| Power (Watts) | 6.24 W |
| RPM | 2540 RPM |
| Size / Dimension [x] | 120 mm |
| Size / Dimension [y] | 120 mm |
| Static Pressure | 0.228 in H2O |
| Static Pressure | 56.8 Pa |
| Termination | 2 Wire Leads |
| Voltage - Rated [custom] | 48 VDC |
| Voltage Range [Max] | 52.8 VDC |
| Voltage Range [Min] | 43.2 VDC |
| Weight | 0.518 lb |
| Weight | 234.96 g |
| Width [y] | 38.5 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
FAD1-12038EBMW12
Fan Tubeaxial 48VDC Square - 120mm L x 120mm H Ball 96.3 CFM (2.70m³/min) 2 Wire Leads
