Description
General part information
VFA1-118-5M12
Wide Angle Lens F1 0.013x ~ 0.113x 1/1.8" C-Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | VFA1-118-5M12 |
|---|---|
| Compatible Sensor Size (Max) (Code) | 1/1.8" |
| Depth Of Field | 12.5 mm |
| Diameter | 26.8 mm |
| Field of View Length (Maximum) | 2085 mm |
| Field of View Length (Minimum) | 49.1 mm |
| Field of View Width (Maximum) | 2780 mm |
| Field of View Width (Minimum) | 65.4 mm |
| Filter Pore Size | 0.5 µm |
| Focal Length | 12 mm |
| Focal Ratio | F1 |
| Length | 19.9 mm |
| Magnification (Max) | 0.113 x |
| Magnification (Min) | 0.013 x |
| Mounting Type | C-Mount |
| Operating Temperature (Max) | 50 °C |
| Operating Temperature (Min) | -10 °C |
| TV Distortion | 0.3 % |
| Type | Wide Angle |
| Working Distance (Maximum) | 900 mm |
| Working Distance (Minimum) | 100 mm |
