SG-E-1-G-A-6-A
ActiveRuffy Controls Inc.
SWITCH JOYSTICK PADDLE HALL 5V
SG-E-1-G-A-6-A
ActiveRuffy Controls Inc.
SWITCH JOYSTICK PADDLE HALL 5V
Description
General part information
SG-E-1-G-A-6-A
Joystick, 2 - Axis Analog (Hall Effect) Output
Technical Specifications
Parameters and characteristics for this part
| Specification | SG-E-1-G-A-6-A |
|---|---|
| Actuator Type | Paddle |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Mounting Type | Panel Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Output | Analog (Hall Effect) |
| Panel Cutout Diameter | 57.15 mm |
| Panel Cutout Shape | Circular |
| Switch Function | 4-Way Directional |
| Termination Style | Cable with Connector |
| Type | Joystick, 2 - Axis |
| Voltage - Supply | 5 VDC |
| Voltage Rating - DC | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
