5452358
ActivePhoenix Contact
TERM BLOCK HDR 9POS 5MM
5452358
ActivePhoenix Contact
TERM BLOCK HDR 9POS 5MM
Description
General part information
5452358
9 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.197" (5.00mm) 90°, Right Angle Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 5452358 |
|---|---|
| Color | Black |
| Contact Mating Finish | Tin |
| Contact Tail Length | 0.138 in |
| Current - IEC | 12 A |
| Current - UL | 15 A |
| Features | Mating Flange |
| Header Orientation | Right Angle |
| Header Orientation Angle | 90 ° |
| Insulation Height | 0.339 in |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 9 |
| Pitch | 0.197 in |
| Positions Per Level | 9 |
| Termination Style | Solder |
| Type | Shrouded (4 Side), Male Pins, Header |
| Voltage - IEC | 320 V |
| Voltage - UL | 300 V |
