125LC2500K5HM6
ActiveCornell Dubilier Knowles
CAP FILM 1.2UF 500VAC CHAS MT
125LC2500K5HM6
ActiveCornell Dubilier Knowles
CAP FILM 1.2UF 500VAC CHAS MT
Description
General part information
125LC2500K5HM6
1.2 µF Film Capacitor 500V Polypropylene (PP) Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | 125LC2500K5HM6 |
|---|---|
| Applications | High Pulse, DV/DT, Conduction Cooled |
| Capacitance | 1.2 µF |
| Dielectric Material | Polypropylene (PP) |
| ESR (Equivalent Series Resistance) | 0.5 mOhm |
| Height - Seated (Max) | 1.339 in |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Size / Dimension Length | 1.969 in |
| Size / Dimension Width | 1.969 in |
| Termination | Threaded, Female |
| Tolerance | 10 % |
| Voltage Rating - AC | 500 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
