12STRGRETXL100
ActiveRemington Industries
HOOK-UP STRND 12AWG GREEN 100'
12STRGRETXL100
ActiveRemington Industries
HOOK-UP STRND 12AWG GREEN 100'
Description
General part information
12STRGRETXL100
12 AWG Hook-Up, Automotive Wire 19/25 Green 60V 100.0' (30.5m)
Technical Specifications
Parameters and characteristics for this part
| Specification | 12STRGRETXL100 |
|---|---|
| Cable Type | Hook-Up, Automotive |
| Conductor Material | Copper, Bare |
| Conductor Strand Count | 19 |
| Conductor Strand Gauge | 25 AWG |
| Features | Abrasion Resistant, Solvent Resistant, Oil Resistant, Chemical Resistant |
| Jacket (Insulation) Diameter | 0.128 in |
| Jacket (Insulation) Material | Polyethylene (XLPE) |
| Jacket Color | Green |
| Length | 100 ft |
| Operating Temperature | 125 °C |
| Voltage | 60 V |
| Wire Gauge | 12 AWG |
