Description
General part information
AM150HB-11015SA30JZ-K
Isolated Module DC DC Converter 1 Output 15V 10A 43V - 160V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | AM150HB-11015SA30JZ-K |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE |
| Current - Output (Max) | 10 A |
| Efficiency | 89 % |
| Features | Heat Sink, Adjustable Output, Remote On/Off, Remote Sense |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Half Brick |
| Power (Watts) | 150 W |
| Size / Dimension Height | 1.25 in |
| Size / Dimension Length | 2.44 in |
| Size / Dimension Width | 2.28 in |
| Type | Isolated Module |
| Voltage - Input (Max) | 160 VDC |
| Voltage - Input (Min) | 43 V |
| Voltage - Isolation | 3 kV |
| Voltage - Output 1 | 15 V |
