EAC14-50-3P
ActiveEaton - Electronics Division
FUSE EV 50A 420VAC 500VDC 3P
EAC14-50-3P
ActiveEaton - Electronics Division
FUSE EV 50A 420VAC 500VDC 3P
Description
General part information
EAC14-50-3P
50A 420 VAC 500 VDC Fuse Cartridge Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | EAC14-50-3P |
|---|---|
| Applications | Electrical, Industrial |
| Breaking Capacity (AC) | 6 kA |
| Breaking Capacity (DC) | 20 kA |
| Current Rating | 50 A |
| DC Cold Resistance | 0.00195 Ohms |
| Fuse Type | Cartridge |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Radial Bend Cylinder |
| Size / Dimension Diameter | 0.589 in |
| Size / Dimension Length | 1.555 in |
| Voltage Rating - AC | 420 VAC |
| Voltage Rating - DC | 500 V |
