Specification	2900898

Control Side Cable Retainer Type	Jackscrew Socket
Control Side Connection Gender	Male
Control Side Connection Shape	Rectangular
Control Side Connection Standard	KS Interface
Features	Relay Sockets, LED, Fuses
Length	9.154 in
Operating Temperature (Max)	50 °C
Operating Temperature (Min)	-20 °C
Positions / Poles	50
Process Side Connection	Terminal Blocks, Screw Connection
Voltage - Rated	24 VAC
Width	5.02 in
Wire Gauge (AWG) (Max)	24 AWG
Wire Gauge (AWG) (Min)	12 AWG

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Technical documentation and resources
