FMCA1459-6
ObsoleteFairview Microwave
CBL ASSY SSMCPLUG-SSMCJACK 6
FMCA1459-6
ObsoleteFairview Microwave
CBL ASSY SSMCPLUG-SSMCJACK 6
Description
General part information
FMCA1459-6
Cable Assembly Coaxial SSMC to SSMC RG-178 6.000" (152.40mm)
Technical Specifications
Parameters and characteristics for this part
| Specification | FMCA1459-6 |
|---|---|
| 1st Connector | SSMC Jack |
| 1st Connector Mounting Type | Free Hanging (In-Line) |
| 1st Contact Gender | Female |
| 2nd Connector | SSMC Plug |
| 2nd Connector Mounting Type | Free Hanging (In-Line) |
| 2nd Contact Gender | Male |
| Cable Impedance | 50 Ohms |
| Cable Type | 178, RG |
| Color | Tan |
| Connector Impedance | 50 Ohms |
| Frequency - Max | 12.4 GHz |
| Length | 0.5 ft |
| Operating Temperature (Max) | 165 °C |
| Operating Temperature (Min) | -55 °C |
| Overall Impedance | 50 Ohms |
| Style | SSMC |
