4410.9001
ActiveSCHURTER Inc.
CIR BRKR THRM 10A 240VAC 28VDC
4410.9001
ActiveSCHURTER Inc.
CIR BRKR THRM 10A 240VAC 28VDC
Description
General part information
4410.9001
Circuit Breaker Thermal 10A 240 V AC 28 V DC Push-Push Panel Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | 4410.9001 |
|---|---|
| Actuator Type | Push-Push |
| Approval Agency | EN 60934, GB 17701, UL1077, CSA C22.2 No 235, IEC 60934 |
| Breaker Type | Thermal |
| Current Rating | 10 A |
| Mounting Type | Panel Mount |
| Number of Poles | 1 |
| Voltage Rating - AC | 240 V |
| Voltage Rating - DC | 28 V |
