MAX9934TEVKIT+
ActiveAnalog Devices Inc./Maxim Integrated
KIT EVAL FOR MAX9934T
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAX9934TEVKIT+
ActiveAnalog Devices Inc./Maxim Integrated
KIT EVAL FOR MAX9934T
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAX9934TEVKIT+ | MAX9934 Series |
|---|---|---|
| -3db Bandwidth | - | 5 kHz |
| Amplifier Type | Current Sense | Current Sense |
| Board Type | Fully Populated | Fully Populated |
| Channels per IC | 1 - Single | 1 - Single |
| Current - Input Bias | - | 35 µA |
| Current - Supply | - | 120 µA |
| Current - Supply (Main IC) | 120 µA | 120 µA |
| Mounting Type | - | Surface Mount |
| Number of Circuits | - | 1 |
| Operating Temperature | - | 125 °C |
| Operating Temperature | - | -40 °C |
| Output Type | Single-Ended | Single-Ended |
| Package / Case | - | 8-MSOP, 8-TSSOP |
| Package / Case | - | 0.118 in |
| Package / Case | - | 3 mm |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 8-uMAX/uSOP |
| Utilized IC / Part | MAX9934 | MAX9934 |
| Voltage - Input Offset | - | 10 µV |
| Voltage - Supply Span (Max) | - | 3.6 V |
| Voltage - Supply Span (Min) | - | 2.5 V |
| Voltage - Supply, Single/Dual (±) [Max] | 3.6 V | 3.6 V |
| Voltage - Supply, Single/Dual (±) [Min] | 2.5 V | 2.5 V |
