DS1843D+
ActiveAnalog Devices Inc./Maxim Integrated
IC SAMPL/HOLD 1 CIRCUIT 8UDFN
Deep-Dive with AI
Search across all available documentation for this part.
DS1843D+
ActiveAnalog Devices Inc./Maxim Integrated
IC SAMPL/HOLD 1 CIRCUIT 8UDFN
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | DS1843D+ | DS1843 Series |
|---|---|---|
| Amplifier Type | Sample and Hold | Sample and Hold |
| Board Type | - | Fully Populated |
| Channels per IC | - | 1 - Single |
| Current - Supply | 9 mA | 9 mA |
| Current - Supply (Main IC) | - | 5.7 mA |
| Mounting Type | Surface Mount | Surface Mount |
| Number of Circuits | 1 | 1 |
| Operating Temperature [Max] | 85 °C | 85 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Output Type | - | Differential |
| Package / Case | 8-WFDFN | 8-WFDFN |
| Supplied Contents | - | Board(s) |
| Supplier Device Package | 8-µDFN, 2x2 | 8-µDFN, 2x2 |
| Utilized IC / Part | - | DS1843 |
| Voltage - Input Offset | 3.6 mV | 3.6 mV |
| Voltage - Supply, Single/Dual (±) | - | 2.97 V |
| Voltage - Supply, Single/Dual (±) | - | 5.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
DS1843 Series
IC SAMPL/HOLD 1 CIRCUIT 8UDFN
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Amplifier Type | Number of Circuits | Voltage - Input Offset | Current - Supply | Supplier Device Package | Package / Case | Board Type | Channels per IC | Output Type | Utilized IC / Part | Current - Supply (Main IC) | Supplied Contents | Voltage - Supply, Single/Dual (±) [Min] | Voltage - Supply, Single/Dual (±) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated DS1843D+ | 85 °C | -40 °C | Surface Mount | Sample and Hold | 1 | 3.6 mV | 9 mA | 2x2, 8-µDFN | 8-WFDFN | ||||||||
Analog Devices Inc./Maxim Integrated DS1843D+TRL | 85 °C | -40 °C | Surface Mount | Sample and Hold | 1 | 3.6 mV | 9 mA | 2x2, 8-µDFN | 8-WFDFN | ||||||||
Analog Devices Inc./Maxim Integrated DS1843K | Sample and Hold | Fully Populated | 1 - Single | Differential | DS1843 | 5.7 mA | Board(s) | 2.97 V | 5.5 V |
Description
General part information
DS1843 Series
Sample and Hold Amplifier 1 Circuit 8-µDFN (2x2)
