135HC3B600K2SM6
ActiveCornell Dubilier Knowles
CAP FILM 1.32UF 10% 600VAC CHASS
135HC3B600K2SM6
ActiveCornell Dubilier Knowles
CAP FILM 1.32UF 10% 600VAC CHASS
Description
General part information
135HC3B600K2SM6
1.32 µF Film Capacitor 600V Polypropylene (PP) Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | 135HC3B600K2SM6 |
|---|---|
| Applications | General Purpose |
| Capacitance | 1.32 µF |
| Dielectric Material | Polypropylene (PP) |
| ESR (Equivalent Series Resistance) | 0.3 mOhm |
| Height - Seated (Max) | 2.402 in |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Size / Dimension Length | 2.677 in |
| Size / Dimension Width | 1.189 in |
| Termination | Threaded, Female |
| Tolerance | 10 % |
| Voltage Rating - AC | 600 VAC |
