MDM-51SCBRM7-A174-F222
ActiveITT Cannon, LLC
MDM 51 S COND BOARD RIGHT HT
MDM-51SCBRM7-A174-F222
ActiveITT Cannon, LLC
MDM 51 S COND BOARD RIGHT HT
Description
General part information
MDM-51SCBRM7-A174-F222
51 Position D-Type, Micro-D Receptacle, Female Sockets Connector
Technical Specifications
Parameters and characteristics for this part
| Specification | MDM-51SCBRM7-A174-F222 |
|---|---|
| Connector Layout Pitch | 0.05 |
| Connector Layout Row to Row | 0.1 |
| Connector Style | Micro-D, D-Type |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Contact Material | Copper Alloy |
| Contact Type | Signal |
| Current Rating | 3 A |
| Dielectric Material | Liquid Crystal Polymer (LCP) |
| Flange Feature | Mating Side, Female Screwlock (2-56) |
| Mounting Type | Panel Mount, Through Hole, Right Angle |
| Number of Positions | 51 |
| Number of Rows | 3 |
| Operating Temperature (Max) | 200 °C |
| Operating Temperature (Min) | -55 °C |
| Primary Material | Metal |
| Shell Material, Finish | Electroless, Nickel Plated, Aluminum |
| Termination | Solder |
