Specification	2636-1357

Clamp Material	Steel
Clamp Plating	Nickel Plated
Color	Gray
Contact Material	Electrolytic Copper
Current	85 A
Housing Material	Nylon 6/6, Polyamide, PA66
Mating Orientation	Horizontal with Board
Mounting Type	Through Hole
Number of Levels	1
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-60 °C
Pitch	0.591 in
Plating	Tin Plated
Positions Per Level	7
Voltage	300 V
Wire Gauge (AWG) (Max)	18 AWG
Wire Gauge (AWG) (Min)	4 AWG
Wire Termination	Leg Spring, Screwless, Push-In Spring
