MAX6836FXSD3+
ActiveAnalog Devices Inc./Maxim Integrated
IC SUPERVISOR 1 CHANNEL SC70-4
Deep-Dive with AI
Search across all available documentation for this part.
MAX6836FXSD3+
ActiveAnalog Devices Inc./Maxim Integrated
IC SUPERVISOR 1 CHANNEL SC70-4
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAX6836FXSD3+ | MAX6836 Series |
|---|---|---|
| - | - | |
| Mounting Type | Surface Mount | Surface Mount |
| Number of Voltages Monitored | 1 | 1 |
| Operating Temperature [Max] | 85 °C | 85 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Output | Totem Pole, Push-Pull | Totem Pole, Push-Pull |
| Package / Case | SC-82A, SOT-343 | SC-82A, SOT-343 |
| Reset | Active High | Active High |
| Reset Timeout | - | 70 µs |
| Reset Timeout [Min] | 140 ms | 140 ms |
| Supplier Device Package | SC-70-4 | SC-70-4 |
| Type | Voltage Detector | Simple Reset/Power-On Reset, Voltage Detector |
| Voltage - Threshold | 1.05 V | 1.05 - 1.665 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 229 | $ 1.31 | |
MAX6836 Series
IC SUPERVISOR 1 CHANNEL SC70-4
| Part | Mounting Type | Voltage - Threshold | Number of Voltages Monitored | Reset | Operating Temperature [Max] | Operating Temperature [Min] | Output | Type | Supplier Device Package | Reset Timeout [Min] | Package / Case | Reset Timeout |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAX6836HXSD3+ | Surface Mount | 1.665 V | 1 | Active High | 85 °C | -40 °C | Push-Pull, Totem Pole | Simple Reset/Power-On Reset | SC-70-4 | 140 ms | SC-82A, SOT-343 | |
Analog Devices Inc./Maxim Integrated MAX6836HXSD0+T | Surface Mount | 1.665 V | 1 | Active High | 85 °C | -40 °C | Push-Pull, Totem Pole | Simple Reset/Power-On Reset | SC-70-4 | 140 ms | SC-82A, SOT-343 | |
Analog Devices Inc./Maxim Integrated MAX6836VXSD3 | Surface Mount | 1.665 V | 1 | Active High | 85 °C | -40 °C | Push-Pull, Totem Pole | Simple Reset/Power-On Reset | SC-70-4 | 140 ms | SC-82A, SOT-343 | |
Analog Devices Inc./Maxim Integrated MAX6836FXSD3+T | Surface Mount | 1.665 V | 1 | Active High | 85 °C | -40 °C | Push-Pull, Totem Pole | Simple Reset/Power-On Reset | SC-70-4 | 140 ms | SC-82A, SOT-343 | |
Analog Devices Inc./Maxim Integrated MAX6836HXSD0+ | Surface Mount | 1.313 V | 1 | Active High | 85 °C | -40 °C | Push-Pull, Totem Pole | Voltage Detector | SC-70-4 | SC-82A, SOT-343 | 70 µs | |
Analog Devices Inc./Maxim Integrated MAX6836VXSD3+ | Surface Mount | 1.665 V | 1 | Active High | 85 °C | -40 °C | Push-Pull, Totem Pole | Simple Reset/Power-On Reset | SC-70-4 | 140 ms | SC-82A, SOT-343 | |
Analog Devices Inc./Maxim Integrated MAX6836VXSD0+ | Surface Mount | 1.575 V | 1 | Active High | 85 °C | -40 °C | Push-Pull, Totem Pole | Voltage Detector | SC-70-4 | SC-82A, SOT-343 | 70 µs | |
Analog Devices Inc./Maxim Integrated MAX6836FXSD3+T | ||||||||||||
Analog Devices Inc./Maxim Integrated MAX6836FXSD3+ | Surface Mount | 1.05 V | 1 | Active High | 85 °C | -40 °C | Push-Pull, Totem Pole | Voltage Detector | SC-70-4 | 140 ms | SC-82A, SOT-343 | |
Analog Devices Inc./Maxim Integrated MAX6836VXSD3+T | Surface Mount | 1.665 V | 1 | Active High | 85 °C | -40 °C | Push-Pull, Totem Pole | Simple Reset/Power-On Reset | SC-70-4 | 140 ms | SC-82A, SOT-343 | |
Analog Devices Inc./Maxim Integrated MAX6836VXSD0+T | Surface Mount | 1.665 V | 1 | Active High | 85 °C | -40 °C | Push-Pull, Totem Pole | Simple Reset/Power-On Reset | SC-70-4 | 140 ms | SC-82A, SOT-343 |
Description
General part information
MAX6836 Series
Supervisor Push-Pull, Totem Pole 1 Channel SC-70-4
