1704360
ActivePhoenix Contact
TERM BLOCK HDR 24POS 3.81MM
1704360
ActivePhoenix Contact
TERM BLOCK HDR 24POS 3.81MM
Description
General part information
1704360
24 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.150" (3.81mm) 90°, Right Angle Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 1704360 |
|---|---|
| Color | Gray |
| Contact Mating Finish | Tin |
| Current - IEC | 8 A |
| Current - UL | 8 A |
| Header Orientation | Right Angle |
| Header Orientation Angle | 90 ° |
| Mounting Type | Through Hole |
| Number of Levels | 2 |
| Number of Positions | 24 pos |
| Pitch | 0.15 in |
| Positions Per Level | 12 |
| Termination Style | Solder |
| Type | Shrouded (4 Side), Male Pins, Header |
| Voltage - IEC | 320 V |
| Voltage - UL | 300 V |
