628-W09-220-012
ActiveEDAC Inc.
CONN D-SUB RCPT 25P PNL MNT SLDR
Deep-Dive with AI
Search across all available documentation for this part.
628-W09-220-012
ActiveEDAC Inc.
CONN D-SUB RCPT 25P PNL MNT SLDR
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 628-W09-220-012 |
|---|---|
| Color | Black |
| Connector Style | D-Sub |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Contact Finish Thickness | Flash |
| Contact Material | Copper Alloy |
| Contact Type | Signal and Power |
| Current Rating (Amps) | 5 A |
| Dielectric Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Flange Feature | Female Screwlock (4-40), Mating Side |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole, Panel Mount |
| Number of Rows | 2 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -25 °C |
| Shell Material, Finish | Nickel Plated, Steel |
| Shell Size, Connector Layout [custom] | DE, E |
| Shell Size, Connector Layout [custom] | 1 |
| Termination | Solder |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 15.73 | |
| 10 | $ 12.09 | |||
| 48 | $ 10.20 | |||
| 96 | $ 9.48 | |||
| 144 | $ 9.10 | |||
| 288 | $ 8.49 | |||
| 528 | $ 8.00 | |||
| 1008 | $ 7.53 | |||
Description
General part information
628-W09 Series
25 Position D-Sub Receptacle, Female Sockets Connector
Documents
Technical documentation and resources
