VLS3015ET-330M
NRNDTDK Corporation
FIXED IND 33UH 390MA 984MOHM SMD
VLS3015ET-330M
NRNDTDK Corporation
FIXED IND 33UH 390MA 984MOHM SMD
Description
General part information
VLS3015ET-330M
33 µH Shielded Drum Core, Wirewound Inductor 390 mA 984mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | VLS3015ET-330M |
|---|---|
| Current - Saturation (Isat) | 0.39 mA |
| Current Rating | 390 mA |
| DC Resistance (DCR) (Max) | 984 mOhm |
| Height - Seated (Max) | 0.059 in |
| Inductance | 33 µH |
| Inductance Frequency - Test | 1 MHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.118 in |
| Size / Dimension Width | 0.118 in |
| Tolerance | 20 % |
| Type | Drum Core, Wirewound |
