5431686
ActivePhoenix Contact
TERM BLOCK HDR 14POS VERT 3.81MM
5431686
ActivePhoenix Contact
TERM BLOCK HDR 14POS VERT 3.81MM
Description
General part information
5431686
14 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.150" (3.81mm) Vertical Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 5431686 |
|---|---|
| Color | Gray |
| Contact Mating Finish | Tin |
| Contact Tail Length | 0.134 in |
| Current - IEC | 8 A |
| Current - UL | 8 A |
| Header Orientation | Vertical |
| Housing Material | Nylon, Polyamide, PA |
| Insulation Height | 0.362 in |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 14 |
| Pitch | 0.15 in |
| Positions Per Level | 14 |
| Termination Style | Solder |
| Type | Shrouded (4 Side), Male Pins, Header |
| Voltage - IEC | 320 V |
| Voltage - UL | 300 V |
