Pluggable Terminal Blocks 7 Pos 3.5mm pitch Plug 24-16AWG Spring
Technical documentation and resources
Parameters and characteristics commom to parts in this series
| Specification | 1952199 | FMC Series |
|---|---|---|
| Color | Green | Black, Green |
| Contact Mating Finish | Tin | Gold, Tin |
| Current - IEC | 8 A | 6 - 8 A |
| Current - UL | 8 A | 6 - 8 A |
| Features | Latch Lock | Latch Lock, Mating Flange |
| Housing Material | Polyamide (PA), Nylon | Liquid Crystal Polymer (LCP), Polyamide (PA), Nylon |
| Insulation Height | - | 5.4 mm |
| Insulation Height | - | 0.213 in |
| Material Flammability Rating | UL94 V-0 | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line) |
| Number of Levels | 1 | 1 |
| Number of Positions | 19 | 6 - 19 |
| Pitch [x] | 3.5 mm | 2.54 - 3.81 mm |
| Pitch [x] | 0.138 in | 0.1 - 0.15 in |
| Positions Per Level | 19 | 6 - 19 |
| Termination Style | Screwless - Push-In Spring | Push-In Spring, Screwless - Leg Spring, Screwless - Push-In Spring |
| Type | Plug, Female Sockets | Plug, Female Sockets |
| Voltage - IEC | 320 V | 160 - 320 V |
| Voltage - UL | 150 V | 150 V |
| Wire Gauge or Range - AWG [Max] | 24 AWG | 24 - 26 AWG |
| Wire Gauge or Range - AWG [Min] | 16 AWG | 16 - 20 AWG |
| Wire Gauge or Range - mm˛ | - | 0.14 mm˛ |
| Wire Gauge or Range - mm˛ | - | 0.5 mm˛ |
| Wire Gauge or Range - mm² [Max] | 1.5 mm² | 1.5 mm² |
| Wire Gauge or Range - mm² [Min] | 0.2 mm² | 0.2 mm² |
| Wire Strip Length | 10 mm | 7 - 10 mm |
Pluggable Terminal Blocks 7 Pos 3.5mm pitch Plug 24-16AWG Spring
| Part | Number of Levels | Wire Gauge or Range - AWG [Max] | Wire Gauge or Range - AWG [Min] | Voltage - IEC | Housing Material | Current - UL | Pitch [x] | Pitch [x] | Positions Per Level | Voltage - UL | Mounting Type | Contact Mating Finish | Number of Positions | Termination Style | Material Flammability Rating | Color | Insulation Height | Insulation Height [z] | Wire Strip Length | Type | Current - IEC | Wire Gauge or Range - mm˛ [Min] | Wire Gauge or Range - mm˛ [Max] | Features | Wire Gauge or Range - mm² [Min] | Wire Gauge or Range - mm² [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Phoenix Contact 1706239 | 1 | 26 AWG | 20 AWG | 160 V | Liquid Crystal Polymer (LCP) | 6 A | 2.54 mm | 0.1 in | 6 | 150 V | Free Hanging (In-Line) | Gold | 6 | Push-In Spring, Screwless - Leg Spring | UL94 V-0 | Black | 5.4 mm | 0.213 in | 7 mm | Plug, Female Sockets | 6 A | 0.14 mm˛ | 0.5 mm˛ | |||
Phoenix Contact 1952199 | 1 | 24 AWG | 16 AWG | 320 V | Polyamide (PA), Nylon | 8 A | 3.5 mm | 0.138 in | 19 | 150 V | Free Hanging (In-Line) | Tin | 19 | Screwless - Push-In Spring | UL94 V-0 | Green | 10 mm | Plug, Female Sockets | 8 A | Latch Lock | 0.2 mm² | 1.5 mm² | ||||
Phoenix Contact 1966224 | 1 | 24 AWG | 16 AWG | 320 V | Polyamide (PA), Nylon | 8 A | 3.5 mm | 0.138 in | 15 | 150 V | Free Hanging (In-Line) | Tin | 15 | Screwless - Push-In Spring | UL94 V-0 | Green | 10 mm | Plug, Female Sockets | 8 A | Mating Flange | 0.2 mm² | 1.5 mm² | ||||
Phoenix Contact 1798375 | 1 | 24 AWG | 16 AWG | 160 V | 8 A | 3.81 mm | 0.15 in | 10 | 150 V | Free Hanging (In-Line) | Gold | 10 | Screwless - Push-In Spring | Black | 10 mm | Plug, Female Sockets | 8 A | Mating Flange | 0.2 mm² | 1.5 mm² |
