TJE120822

Active

AMPHENOL PCD

CONN DIODE MOD SZ16/20 0.850" L

Search across all available documentation for this part.

Active

AMPHENOL PCD

CONN DIODE MOD SZ16/20 0.850" L

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Connector Module, Diode Contact Size 16, 20

Technical documentation and resources

Specification	TJE120822	TJE12 Series

	-	-
Contact Size	20, 16	16 - 22
Module Capacity	10	4 - 10
Size / Dimension [x]	0.85 "	0.85 "
Size / Dimension [x]	21.59 mm	21.59 mm
Size / Dimension [y]	0.39 "	0.39 "
Size / Dimension [y]	9.91 mm	9.91 mm
Size / Dimension [z]	33.27 mm	33.27 mm
Size / Dimension [z]	1.31 "	1.31 "
Type	Diode, Module	Module, Resistor, Diode, Module, Module, Capacitor

Part	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Contact Size	Module Capacity	Type	Size / Dimension [y]	Size / Dimension [y]
AMPHENOL PCD TJE120928	33.27 mm	1.31 "	21.59 mm	0.85 "	20	10	Module, Resistor
AMPHENOL PCD TJE120827	33.27 mm	1.31 "	21.59 mm	0.85 "	20	8	Diode, Module	0.39 "	9.91 mm
AMPHENOL PCD TJE120515					16, 20	10	Module, Capacitor
AMPHENOL PCD TJE120911	33.27 mm	1.31 "	21.59 mm	0.85 "	20	10	Module, Resistor	0.39 "	9.91 mm
AMPHENOL PCD TJE120905	33.27 mm	1.31 "	21.59 mm	0.85 "	20	6	Module, Resistor	0.39 "	9.91 mm
AMPHENOL PCD TJE120843	33.27 mm	1.31 "	21.59 mm	0.85 "	20	10	Module, Resistor
AMPHENOL PCD TJE120917	33.27 mm	1.31 "	21.59 mm	0.85 "	20	6	Module, Resistor	0.39 "	9.91 mm
AMPHENOL PCD TJE120828	33.27 mm	1.31 "	21.59 mm	0.85 "	20	4	Diode, Module	0.39 "	9.91 mm
AMPHENOL PCD TJE120842	33.27 mm	1.31 "	21.59 mm	0.85 "	20	10	Module, Resistor
AMPHENOL PCD TJE120929	33.27 mm	1.31 "	21.59 mm	0.85 "	20	4	Module, Resistor
