Description
General part information
173107 Series
D-Sub Mixed Contact Connectors FCT ML DSUB RA PC PLG 24W7 W/CLINCH
Technical Specifications
Parameters and characteristics for this part
| Specification | 1731070168 |
|---|---|
| Color | Black |
| Connector Layout | DC, C |
| Connector Style | Combo, D-Sub |
| Connector Type | Receptacle for Female Contacts |
| Contact Type | Coax or Power, Coax, Power |
| Dielectric Material | Polybutylene Terephthalate (PBT) |
| Finish | Tin Plated |
| Flange Feature | Cable Side (4-40) |
| Mounting Type | Free Hanging (In-Line) |
| Note | Contacts Not Included |
| Number of Positions | 7 |
| Number of Rows | 1 |
| Operating Temperature (Max) | 130 °C |
| Operating Temperature (Min) | -55 °C |
| Part Code | 7W7 |
| Position Types | Power, Coax |
| Shell Material | Steel |
| Shell Size | 4 |
