Part	Resistance	Tolerance	Number of Turns	Adjustment Type	Termination Style	Resistive Material	Actuator Length	Actuator Diameter	Mounting Type	Rotation	Taper	Size - Body Shape	Size - Body Diameter	Number of Gangs	Actuator Type	Power (Watts)	Power (Watts) Options	Built in Switch	Features	Bushing Thread Diameter	Bushing Thread	Bushing Thread Pitch
TT Electronics/BI P232-DEC20BR10K	10 kOhm	10 %	1 turns	User Defined	Solder Lug	Conductive Plastic	0.787 in	6.35 mm	Panel Mount	300 °	Linear	Round	0.906 in	1	Slotted	500 mW	1/2W	None	Sealed	9 mm	M9 x 0.75	0.75 mm
TT Electronics/BI P232-DFC35AR100K	100 kOhm	10 %	1 turns	User Defined	Solder Lug	Conductive Plastic	1.378 in	6.35 mm	Panel Mount	300 °	Logarithmic	Round	0.906 in	1	Flatted	300 mW	3/10W	None	Sealed	9 mm	M9 x 0.75	0.75 mm
TT Electronics/BI P232-SEC20BR5K	5 kOhm	10 %	1 turns	User Defined	Solder Lug	Conductive Plastic	0.787 in	6.35 mm	Panel Mount	300 °	Linear	Round	0.906 in	1	Slotted	500 mW	1/2W	None	Sealed	9 mm	M9 x 0.75	0.75 mm
TT Electronics/BI P232-SFC25BR10K	10 kOhm	10 %	1 turns	User Defined	Solder Lug	Conductive Plastic	0.984 in	6.35 mm	Panel Mount	300 °	Linear	Round	0.906 in	1	Flatted	500 mW	1/2W	None	Sealed	9 mm	M9 x 0.75	0.75 mm
TT Electronics/BI P232-SEA20BR100K	100 kOhm	10 %	1 turns	User Defined	Solder Lug	Conductive Plastic	0.787 in	6.35 mm	Panel Mount	300 °	Linear	Round	0.906 in	1	Slotted	500 mW	1/2W	None	Sealed	9 mm	M9 x 0.75	0.75 mm
TT Electronics/BI P232-SEC35BR5K	5 kOhm	10 %	1 turns	User Defined	Solder Lug	Conductive Plastic	1.378 in	6.35 mm	Panel Mount	300 °	Linear	Round	0.906 in	1	Slotted	500 mW	1/2W	None	Sealed	9 mm	M9 x 0.75	0.75 mm
TT Electronics/BI P232-DEC30BR2K	2 kOhm	10 %	1 turns	User Defined	Solder Lug	Conductive Plastic	1.181 in	6.35 mm	Panel Mount	300 °	Linear			1	Slotted	500 mW	1/2W	None	Sealed	9 mm	M9 x 0.75	0.75 mm
TT Electronics/BI P232-DEC22BR100K	100 kOhm	10 %	1 turns	User Defined	Solder Lug	Conductive Plastic	0.866 in	6.35 mm	Panel Mount	300 °	Linear	Round	0.906 in	1	Slotted	500 mW	1/2W	None	Sealed	9 mm	M9 x 0.75	0.75 mm
TT Electronics/BI P232-SEC20BR1MEG	1 MOhm	10 %	1 turns	User Defined	Solder Lug	Conductive Plastic	0.787 in	6.35 mm	Panel Mount	300 °	Linear	Round	0.906 in	1	Slotted	500 mW	1/2W	None	Sealed	9 mm	M9 x 0.75	0.75 mm
TT Electronics/BI P232-SEA20BR10K	10 kOhm	10 %	1 turns	User Defined	Solder Lug	Conductive Plastic	0.787 in	6.35 mm	Panel Mount	300 °	Linear	Round	0.906 in	1	Slotted	500 mW	1/2W	None	Sealed	9 mm	M9 x 0.75	0.75 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

Datasheet
