Specification	FH33J-18S-0.5SH(10)

Actuator Material	Polyphenylene Sulfide (PPS)
Cable End Type	Tapered
Connector/Contact Type	Contacts, Bottom
Contact Finish	Gold
Contact Finish Thickness	0
Contact Finish Thickness	Flash
Contact Finish Thickness (string set options)	Flash
Contact Material	Phosphor Bronze
Current Rating	0.5 A
Features	Zero Insertion Force (ZIF)
FFC, FCB Thickness	0.3 mm
Flat Flex Type	FFC, FPC
Height Above Board	0.047 in
Housing Material	LCP, Liquid Crystal Polymer, Halogen Free
Locking Feature	Flip Lock
Mating Cycles	20 cycles
Mounting Type	Right Angle, Surface Mount
Number of Positions	18
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-55 °C
Pitch	0.02 in
Termination	Solder
Voltage Rating	50 V

FH33 Series

Part	Pitch	Actuator Material	Connector/Contact Type	FFC, FCB Thickness	Housing Material	Termination	Operating Temperature (Min)	Operating Temperature (Max)	Flat Flex Type	Contact Finish	Material Flammability Rating	Voltage Rating	Mounting Type	Cable End Type	Contact Material	Features	Locking Feature	Height Above Board	Number of Positions	Mating Cycles	Current Rating	Contact Finish Thickness	Contact Finish Thickness (string set options)	Contact Finish Thickness	Housing Color	Actuator Color
Hirose Electric Co Ltd FH33-32S-0.5SH(10)	0.02 in	Nylon Polyamide (PA)	Bottom Contacts	0.3 mm	Nylon PA Polyamide	Solder	-55 °C	85 °C	FFC FPC	Gold	UL94 V-0	50 V	Right Angle Surface Mount	Tapered	Phosphor Bronze	Zero Insertion Force (ZIF)	Flip Lock	0.047 in	32	20 cycles	0.5 A	0	Flash	Flash
Hirose Electric Co Ltd FH33-45S-0.5SH(99)	0.02 in	Nylon Polyamide (PA)	Bottom Contacts	0.3 mm	Nylon PA Polyamide	Solder	-55 °C	85 °C	FFC FPC	Gold	UL94 V-0	50 V	Right Angle Surface Mount	Tapered	Phosphor Bronze	Zero Insertion Force (ZIF)	Flip Lock	0.047 in	45	20 cycles	0.5 A
Hirose Electric Co Ltd FH33-30S-0.5SH	0.02 in	Nylon Polyamide (PA)	Bottom Contacts	0.3 mm	Nylon PA Polyamide	Solder	-55 °C	85 °C	FFC FPC	Gold	UL94 V-0	50 V	Right Angle Surface Mount	Tapered	Phosphor Bronze	Zero Insertion Force (ZIF)	Flip Lock	0.047 in	30		0.5 A	0	Flash	Flash
Hirose Electric Co Ltd FH33-6S-0.5SH(10)	0.02 in	Nylon Polyamide (PA)	Bottom Contacts	0.3 mm	Nylon PA Polyamide	Solder	-55 °C	85 °C	FFC FPC	Gold	UL94 V-0	50 V	Right Angle Surface Mount	Tapered	Phosphor Bronze	Zero Insertion Force (ZIF)	Flip Lock	0.047 in	6	20 cycles	0.5 A	0	Flash	Flash
Hirose Electric Co Ltd FH33J-40S-0.5SH(10)	0.02 in	Polyphenylene Sulfide (PPS)	Bottom Contacts	0.3 mm	Halogen Free LCP Liquid Crystal Polymer	Solder	-55 °C	85 °C	FFC FPC	Gold		50 V	Right Angle Surface Mount	Tapered	Phosphor Bronze	Zero Insertion Force (ZIF)	Flip Lock	0.047 in	40	20 cycles	0.5 A	0	Flash	Flash
Hirose Electric Co Ltd FH33-30S-0.5SH(99)	0.02 in	Nylon Polyamide (PA)	Bottom Contacts	0.3 mm	Nylon PA Polyamide	Solder	-55 °C	85 °C	FFC FPC	Gold	UL94 V-0	50 V	Right Angle Surface Mount	Tapered	Phosphor Bronze	Zero Insertion Force (ZIF)	Flip Lock	0.047 in	30	20 cycles	0.5 A
Hirose Electric Co Ltd FH33J-10S-0.5SH(99)	0.02 in	Polyphenylene Sulfide (PPS)	Bottom Contacts	0.3 mm	Halogen Free LCP Liquid Crystal Polymer	Solder	-55 °C	85 °C	FFC FPC	Gold		50 V	Right Angle Surface Mount	Tapered	Phosphor Bronze	Zero Insertion Force (ZIF)	Flip Lock	0.047 in	10	20 cycles	0.5 A
Hirose Electric Co Ltd FH33-45S-0.5SH(10)	0.02 in	Nylon Polyamide (PA)	Bottom Contacts	0.3 mm	Nylon PA Polyamide	Solder	-55 °C	85 °C	FFC FPC	Gold	UL94 V-0	50 V	Right Angle Surface Mount	Tapered	Phosphor Bronze	Zero Insertion Force (ZIF)	Flip Lock	0.047 in	45	20 cycles	0.5 A	0	Flash	Flash
Hirose Electric Co Ltd FH33-12S-0.5SH(99)	0.02 in	Nylon Polyamide (PA)	Bottom Contacts	0.3 mm	Nylon PA Polyamide	Solder	-55 °C	85 °C	FFC FPC	Gold	UL94 V-0	50 V	Right Angle Surface Mount	Tapered	Phosphor Bronze	Zero Insertion Force (ZIF)	Flip Lock	0.047 in	12	20 cycles	0.5 A
Hirose Electric Co Ltd FH33W-6S-0.5SH(10)	0.02 in	Nylon Polyamide (PA)	Bottom Contacts	0.3 mm	LCP Liquid Crystal Polymer	Solder	-55 °C	85 °C	FFC FPC	Gold	UL94 HB	50 V	Right Angle Surface Mount	Tapered	Phosphor Bronze	Zero Insertion Force (ZIF)	Flip Lock	0.047 in	6		0.5 A	2 µin			Beige	Brown
