PCHC420Z2-6R8M-RC
ActiveAllied Components International
6.8UH +/-20% SMD PWR CHIP INDUCT
PCHC420Z2-6R8M-RC
ActiveAllied Components International
6.8UH +/-20% SMD PWR CHIP INDUCT
Description
General part information
PCHC420Z2-6R8M-RC
6.8 µH Shielded Inductor 1.8 A 172mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | PCHC420Z2-6R8M-RC |
|---|---|
| Current - Saturation (Isat) | 2.5 A |
| Current Rating | 1.8 A |
| DC Resistance (DCR) (Max) | 172 mOhm |
| Height - Seated (Max) | 0.079 in |
| Inductance | 6.8 µH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.175 in |
| Size / Dimension Width | 0.16 in |
| Tolerance | 20 % |
